1440-TB-A

Allows communication via DeviceNet™ network Supports Dynamix 2500 and Enpac 2500 Data Collectors Supports maximum of 10 1440-DYN02-01RJ Dynamic Measurement Modules on a ControlNet™ network Offers built-in and user editable rule sets Includes two tachometer inputs, each measures 25V (50V max. peak to peak) Offers live data view from any 1444 series monitor on any machine, by any user from any location Module I/O and configuration tables are exposed as common tags in the Studio 5000 Logix Designer application Communicates via ControlNet™ network (connected through a 1440-ACNR ControlNet Adapter) Includes one tachometer channel that accepts input from most speed measurement sensors and can measure speeds 11.2M RPM with pulse rates 150,000 events per revolution Includes single on-board relay Offers single on-board relay Includes one virtual relay Includes two channels which connect common vibration sensors (e.g., eddy current probes, accelerometers) and any sensor that outputs a voltage signal Allows the ability to import/export data from any OPC server Includes one digital output for use with an XM-442 EODS Relay module Includes four virtual relays or four additional relays (when connected to an XM® 441 Expansion Relay Module) Allows tags to be imported from a Logix controller, scheduled or on demand Includes fault frequency identification Provides ability to monitor shaft, casing, or pedestal vibration in rotating equipment Includes two channels connect common vibration sensors (e.g., eddy current probes, accelerometers) and any sensor that outputs a voltage signal Provides ability to schedule automated data collection from any number of 1444 series or 1440 series monitors or machines Includes the ability to download defect frequencies to collectors Offers signal processing which provides two levels of integration and FFT processing with as many as 30 measured parameters Includes module configuration managed by a ControlLogix® controller and the Studio 5000™ Logix Designer application Offers signal processing which provides synchronous or asynchronous measurements

Technical Specifications

Applications : XM-12x Module Terminal Base Mounting Type : DIN Rail, Panel Operating Temperature : 149 degrees F Output : 0 Size : 98 x 95 x 57 mm Standard : CE,CUL,KC,RCM,UL TC Connection : Screw Clamp Temperature Rating : -25 to 65 degrees C Type : Terminal Base Voltage : 24 Volt
