Prevents incorrect positioning of module with software keying
Offers support for Integrated Motion over EtherNet/IP™ for maximized scalability
Provides support for Device Level Ring (DLR) network topologies to help increase network resiliency
Provide individually configurable channels
Includes individual point diagnostic status indicators to ease troubleshooting
Include high speed input modules
Delivers standard, safety and motion control for On-Machine™ applications
Allow control migrations with re-use of existing 1769 I/O
Require SERCOS interface modules for motion
Does not require a chassis
Include on-board scaling
Offers open socket capability that allows support for Modbus TCP as well as devices such as printers, barcode readers and servers
Provides up to 16 axes of Integrated Motion over EtherNet/IP
Include I/O packet rate of 10,000 pps
Offers built-in communication ports for EtherNet/IP or ControlNet networks
Direct 1769 platform connection to PowerFlex® drives and other devices through Compact I/O™ to DPI/SCANport™ and Compact I/O to DSI/Modbus modules
Simplify your system architecture with distributed I/O over EtherNet/IP
Offer direct connection
Removes the need for lithium batteries with built-in energy storage
Lets you control distributed I/O via EtherNet/IP, ControlNet, or DeviceNet (select models only)
Includes a built-in RS-232 serial port on every 1769-L3x controller
Supports integrated safety up to SIL 3, PLe CAT 4
Provides seamless bridging with data control and collection over the same network
Available with conformal coating
Provide dual Ethernet ports for both DLR and linear topologies
Offer analog, thermocouple, and RTD modules
Offer input filtering
Address reserve, ASCII, Boolean control, and high-speed counter modules available
Support single network strategy to EtherNet/IP TCP/CIP connection 96
Include over-range and under-range detection and indication
Include autocalibration of inputs
Provides ability to connect with scaled HMI options from the PanelView™ Plus portfolio to PanelView 800 graphic terminals for simple features
Integrate with 1769 Compact I/O™ modules
Support seamless bridging with data control and collection over the same network
Includes up to a 2-GB secure digital (SD) card for fast program save and restore
Require a chassis
Provides flexibility with DIN rail or panel mounting options
Provides integrated safety and integrated motion in a single controller
Support SIL 3, PLe integrity (L4xS controllers only)
Include 832 points per module
Include ability to direct output device operation during an abnormal condition
Provide optical isolation
Includes a 1769-SDN communication interface module for I/O control and remote device configuration over DeviceNet
Let you control distributed I/O via EtherNet/IP, ControlNet, or DeviceNet
Supports up to 2 axes Kinematics for simple articulated robotics
Offers a smaller form factor for maximized cabinet space
Offer user memory options ranging 2 MB to 3 MB
Offer selectable response to a broken input sensor
Offer a variety of AC and DC voltages
Provide high accuracy ratings
Offers flexible user memory options
Provide integrated serial port
Include contact output modules
Integrates with 1769 Compact I/O™ modules
Permit on-line editing, forcing and other standard activities while securely isolating safety functionality (L4xS controllers only)
Connects as many as three banks of Compact I/O™ to a controller; requires use of a communication adapter module and power supply
Ideal for small, to mid-size applications that require low axis motion and I/O point counts
Technical Specifications
Amperage : 250 mA Input, 0.115 Amp Output
Display Type : Status LEDs
Input Voltage : 79-132 V
Mounting Type : DIN Rail,Panel Mount
Number of Channels : 16
Operating Temperature : 0 To 60 degrees C
Power Supply : 115 mA at 5VDC (0.575W)
Response Time : 20 Millisecond
Standard : C-TICK,CCC,CUL,GOST,KC,MARINE,UL
TC Connection : Plug-in
Type : Digital Input
Voltage : 79-132 VAC at 50/60 Hz Supply, 5.1 VAC Output, 100-120 VAC Input
