Provides integrated safety and integrated motion in a single controller
Integrates with 1769 Compact I/O™ modules
Permit on-line editing, forcing and other standard activities while securely isolating safety functionality (L4xS controllers only)
Available with conformal coating
Includes up to a 2-GB secure digital (SD) card for fast program save and restore
Offers a smaller form factor for maximized cabinet space
Integrate with 1769 Compact I/O™ modules
Provides support for Device Level Ring (DLR) network topologies to help increase network resiliency
Include ability to direct output device operation during an abnormal condition
Include autocalibration of inputs
Offer a variety of AC and DC voltages
Provide individually configurable channels
Connects as many as three banks of Compact I/O™ to a controller; requires use of a communication adapter module and power supply
Supports integrated safety up to SIL 3, PLe CAT 4
Includes a built-in RS-232 serial port on every 1769-L3x controller
Offers open socket capability that allows support for Modbus TCP as well as devices such as printers, barcode readers and servers
Require a chassis
Lets you control distributed I/O via EtherNet/IP, ControlNet, or DeviceNet (select models only)
Direct 1769 platform connection to PowerFlex® drives and other devices through Compact I/O™ to DPI/SCANport™ and Compact I/O to DSI/Modbus modules
Offer user memory options ranging 2 MB to 3 MB
Prevents incorrect positioning of module with software keying
Simplify your system architecture with distributed I/O over EtherNet/IP
Allow control migrations with re-use of existing 1769 I/O
Removes the need for lithium batteries with built-in energy storage
Ideal for small, to mid-size applications that require low axis motion and I/O point counts
Support single network strategy to EtherNet/IP TCP/CIP connection 96
Offers built-in communication ports for EtherNet/IP or ControlNet networks
Provide integrated serial port
Provides flexibility with DIN rail or panel mounting options
Provides ability to connect with scaled HMI options from the PanelView™ Plus portfolio to PanelView 800 graphic terminals for simple features
Include on-board scaling
Include over-range and under-range detection and indication
Address reserve, ASCII, Boolean control, and high-speed counter modules available
Offer selectable response to a broken input sensor
Offers support for Integrated Motion over EtherNet/IP™ for maximized scalability
Offer direct connection
Supports up to 2 axes Kinematics for simple articulated robotics
Provide optical isolation
Delivers standard, safety and motion control for On-Machine™ applications
Provides seamless bridging with data control and collection over the same network
Provides up to 16 axes of Integrated Motion over EtherNet/IP
Does not require a chassis
Support SIL 3, PLe integrity (L4xS controllers only)
Include high speed input modules
Support seamless bridging with data control and collection over the same network
Provide high accuracy ratings
Offer analog, thermocouple, and RTD modules
Let you control distributed I/O via EtherNet/IP, ControlNet, or DeviceNet
Include 832 points per module
Offers flexible user memory options
Provide dual Ethernet ports for both DLR and linear topologies
Includes individual point diagnostic status indicators to ease troubleshooting
Includes a 1769-SDN communication interface module for I/O control and remote device configuration over DeviceNet
Require SERCOS interface modules for motion
Include contact output modules
Offer input filtering
Include I/O packet rate of 10,000 pps
Technical Specifications
Amperage : 120 mA at 5 VDC, 70 mA at 24 VDC
Display Type : Status LEDs
Mounting Type : DIN Rail/Panel
Number of Channels : 8
Power Supply : 120 mA at 5VDC, 70 mA at 24VDC
Standard : C-TICK,GOST,KC,MARINE
Type : Conformal Coated
Voltage : +/-10 Volt
