Include ability to direct output device operation during an abnormal condition
Provides support for Device Level Ring (DLR) network topologies to help increase network resiliency
Integrates with 1769 Compact I/O™ modules
Delivers standard, safety and motion control for On-Machine™ applications
Supports integrated safety up to SIL 3, PLe CAT 4
Offer input filtering
Integrate with 1769 Compact I/O™ modules
Provides ability to connect with scaled HMI options from the PanelView™ Plus portfolio to PanelView 800 graphic terminals for simple features
Include high speed input modules
Lets you control distributed I/O via EtherNet/IP, ControlNet, or DeviceNet (select models only)
Provide high accuracy ratings
Includes a 1769-SDN communication interface module for I/O control and remote device configuration over DeviceNet
Provide integrated serial port
Offer analog, thermocouple, and RTD modules
Provides up to 16 axes of Integrated Motion over EtherNet/IP
Require SERCOS interface modules for motion
Offers support for Integrated Motion over EtherNet/IP™ for maximized scalability
Include over-range and under-range detection and indication
Connects as many as three banks of Compact I/O™ to a controller; requires use of a communication adapter module and power supply
Support SIL 3, PLe integrity (L4xS controllers only)
Address reserve, ASCII, Boolean control, and high-speed counter modules available
Require a chassis
Provide optical isolation
Include contact output modules
Ideal for small, to mid-size applications that require low axis motion and I/O point counts
Provides flexibility with DIN rail or panel mounting options
Includes individual point diagnostic status indicators to ease troubleshooting
Provide dual Ethernet ports for both DLR and linear topologies
Offers open socket capability that allows support for Modbus TCP as well as devices such as printers, barcode readers and servers
Offer user memory options ranging 2 MB to 3 MB
Supports up to 2 axes Kinematics for simple articulated robotics
Offers flexible user memory options
Offer selectable response to a broken input sensor
Available with conformal coating
Support single network strategy to EtherNet/IP TCP/CIP connection 96
Include autocalibration of inputs
Provides seamless bridging with data control and collection over the same network
Offer a variety of AC and DC voltages
Offers built-in communication ports for EtherNet/IP or ControlNet networks
Includes a built-in RS-232 serial port on every 1769-L3x controller
Provide individually configurable channels
Offers a smaller form factor for maximized cabinet space
Support seamless bridging with data control and collection over the same network
Allow control migrations with re-use of existing 1769 I/O
Does not require a chassis
Offer direct connection
Include I/O packet rate of 10,000 pps
Provides integrated safety and integrated motion in a single controller
Include 832 points per module
Let you control distributed I/O via EtherNet/IP, ControlNet, or DeviceNet
Direct 1769 platform connection to PowerFlex® drives and other devices through Compact I/O™ to DPI/SCANport™ and Compact I/O to DSI/Modbus modules
Permit on-line editing, forcing and other standard activities while securely isolating safety functionality (L4xS controllers only)
Prevents incorrect positioning of module with software keying
Includes up to a 2-GB secure digital (SD) card for fast program save and restore
Simplify your system architecture with distributed I/O over EtherNet/IP
Removes the need for lithium batteries with built-in energy storage
Include on-board scaling
Technical Specifications
Amperage : 250 mA Input, 0.115 Amp Output
Display Type : Status LEDs
Input Voltage : 10-30 V
Mounting Type : DIN Rail,Panel Mount
Number of Channels : 16
Operating Temperature : 0 To 60 degrees C
Response Time : 8 Millisecond
Standard : C-TICK,CCC,CUL,GOST,KC,MARINE,UL
TC Connection : Plug-in
Type : Digital Input
Voltage : 10-30 VDC Supply, 5.1 VDC Output, 24 VDC Input
