Let you control distributed I/O via EtherNet/IP, ControlNet, or DeviceNet
Support SIL 3, PLe integrity (L4xS controllers only)
Include 832 points per module
Offers built-in communication ports for EtherNet/IP or ControlNet networks
Supports integrated safety up to SIL 3, PLe CAT 4
Includes a 1769-SDN communication interface module for I/O control and remote device configuration over DeviceNet
Available with conformal coating
Provides integrated safety and integrated motion in a single controller
Includes a built-in RS-232 serial port on every 1769-L3x controller
Require SERCOS interface modules for motion
Lets you control distributed I/O via EtherNet/IP, ControlNet, or DeviceNet (select models only)
Include high speed input modules
Offers a smaller form factor for maximized cabinet space
Supports up to 2 axes Kinematics for simple articulated robotics
Offers flexible user memory options
Offer analog, thermocouple, and RTD modules
Offers open socket capability that allows support for Modbus TCP as well as devices such as printers, barcode readers and servers
Delivers standard, safety and motion control for On-Machine™ applications
Connects as many as three banks of Compact I/O™ to a controller; requires use of a communication adapter module and power supply
Allow control migrations with re-use of existing 1769 I/O
Provide optical isolation
Address reserve, ASCII, Boolean control, and high-speed counter modules available
Integrates with 1769 Compact I/O™ modules
Includes up to a 2-GB secure digital (SD) card for fast program save and restore
Offer input filtering
Offer user memory options ranging 2 MB to 3 MB
Include ability to direct output device operation during an abnormal condition
Prevents incorrect positioning of module with software keying
Integrate with 1769 Compact I/O™ modules
Include over-range and under-range detection and indication
Include autocalibration of inputs
Support single network strategy to EtherNet/IP TCP/CIP connection 96
Ideal for small, to mid-size applications that require low axis motion and I/O point counts
Simplify your system architecture with distributed I/O over EtherNet/IP
Includes individual point diagnostic status indicators to ease troubleshooting
Include on-board scaling
Removes the need for lithium batteries with built-in energy storage
Offer selectable response to a broken input sensor
Include I/O packet rate of 10,000 pps
Require a chassis
Provide high accuracy ratings
Provide dual Ethernet ports for both DLR and linear topologies
Provides seamless bridging with data control and collection over the same network
Offers support for Integrated Motion over EtherNet/IP™ for maximized scalability
Support seamless bridging with data control and collection over the same network
Offer a variety of AC and DC voltages
Provides ability to connect with scaled HMI options from the PanelView™ Plus portfolio to PanelView 800 graphic terminals for simple features
Provide integrated serial port
Provides up to 16 axes of Integrated Motion over EtherNet/IP
Include contact output modules
Offer direct connection
Does not require a chassis
Provides support for Device Level Ring (DLR) network topologies to help increase network resiliency
Permit on-line editing, forcing and other standard activities while securely isolating safety functionality (L4xS controllers only)
Provides flexibility with DIN rail or panel mounting options
Direct 1769 platform connection to PowerFlex® drives and other devices through Compact I/O™ to DPI/SCANport™ and Compact I/O to DSI/Modbus modules
Provide individually configurable channels
Technical Specifications
Amperage : 0.205 Amp
Display Type : Status LEDs
Mounting Type : DIN Rail,Panel Mount
Number of Channels : 16
Operating Temperature : 0 To 60 degrees C
Output : 16 Digital
Output Signal : 5-125 V
Response Time : 10 Millisecond
Standard : C-TICK,CCC,CUL,GOST,KC,MARINE,UL
TC Connection : Plug-in
Type : Digital Output
Voltage : 5-125 VDC, 5-265 VAC at 50/60 Hz Supply, 5.1 VAC/VDC Output
